Description
- ENERGY EFFICIENT COOLING: 2 Zone 18,000 BTU/h, 24.5 SEER2, 208-230V, ETL Listed, AHRI Certified air conditioner unit features a ductless mini split inverter plus system with a heat pump (up to -15ā/-25ā) and DC Inverter technology.
- WiFi AND ALEXA COMPATIBILITY: Ductless mini split heat features advanced WiFi control and Alexa compatibility, allowing seamless operation through smart devices. Complete Wi-Fi setup manual included with the indoor unit for easy configuration and smart home integration.
- QUIET OPERATION: This air conditioner operates at an ultra-silent 30 dBA, ensuring a peaceful environment. Balanced airflow distributes air evenly throughout the room, delivering consistent comfort within minutes.
- COMPLETE INSTALLATION KIT: Includes 16-foot insulated copper refrigeration tubing, power cables, interconnecting cables, pipe wrap, and wall sleeve. Professional HVAC installation recommended for optimal performance.
- SMART COMFORT WITH VERSATILE MODES: Innovative features include Auto Restart, 5 operating modes (Auto, Cool, Heater, Dry, Fan), programmable timer, and automatic air swing for comprehensive room coverage. Display dimming capability perfect for bedroom installation.
- MULTIPLE ROOMS: Comes with 2 indoor air handlers 9,000 BTU + 9,000 BTU with separate controller for individual rooms and 1 outdoor 18,000 BTU condenser. Additionally, it uses the R454B refrigerant.\
- EXTRA REMOTE: Temperature & Humidity Display Remote. (Available Upon Warranty Registration)
ERROR SIGNALS THAT DISPLAY ON YOUR UNIT
Understanding the error codes that display on the Indoor Unit.
E0 - (Common at Start Up) - Lost Communication between Indoor and Outdoor Units (if at initial startup, check for miswiring or broken or disconnected Cable #1, Leftmost of 3, may be labelled differently)
E1 - Indoor Temperature Sensor Fault
E2 - Indoor Pipe Temperature Sensor Fault
E3 - Outdoor Pipe Temperature Sensor Fault
E4 - Refrigerant System Leakage or Fault
E6 - Malfunction of the Indoor Fan Motor
E7 - Outdoor Air Temperature Sensor Fault
E8 - Outdoor Discharge Temperature Sensor Fault
E9 - Outdoor IPM Module Fault
EA - Outdoor Current Detect Fault
EE - Outdoor PCB EEPROM Fault
EF - Outdoor Fan Motor Fault
EH - Outdoor Suction Temperature Sensor Fault
FX - Advanced Troubleshooting Codes - Contact Tech Support for Assistance
P4 - Compressor Overload (If at initial startup, check that refrigerant valves are open)
PA - Indoor Unit and Outdoor Unit have different modes or Indoor Unit's water safety float switch has been triggered due to a backed up drain.
FEATURES & SPECS
|
Capacity |
1 Ton |
|
Cooling Power |
18000 British Thermal Units |
|
Additional Features |
Remote Controlled, WiFi Enabled, Extra Remote showing Temperature and Humidity, Heating And Cooling Function |
|
Seasonal Energy Efficiency Ratio (SEER) |
24.5 SEER2 |
|
Voltage |
230 Volts |
|
Noise |
34 dB |
|
Power Source |
Corded Electric |
|
Form Factor |
Mini-Split |
|
Control Method |
App, Remote, Touch, Voice |
|
Inverter Type |
Has Inverter |
|
Controller Type |
Remote Control, App Control, Touch Control |
|
Efficiency |
High |
|
Installation Type |
Split System |
|
Compressor Type |
Inverter Compressor |
|
Is Product Cordless |
No |
|
Is Outdoor Unit Required |
Yes |
|
Air Conditioner Application |
Residential and Commercial |
ITEM INFO
|
Brand Name |
Classic America |
|
Model Number |
MZR454B-DUETSERIES |
|
UPC |
856739008295 |
|
Item Weight (Indoor Unit) |
27 lbs |
|
Item Weight (Outdoor Unit) |
180 lbs |
